| 安装方式 | 埋入式 | 非埋入式 | ||
| 检测距离 | 10mm | 15mm | ||
| 交流AC90-250V | 二线制 | NO 常开 | FJ2-M10KA | FJ2-15KA |
| NC 常闭 | FJ2-M10KB | FJ2-15KB | ||
| 三线制 | NO+NC 常开常闭 | FJ2-M10KE | FJ2-15KE | |
| 继电输出四线 | NO+NC 常开常闭 | FJ2-M10KC | FJ2-15KC | |
| 继电输出五线 | NO+NC 常开常闭 | FJ2-M10JC | FJ2-15JC | |
| 直流DC6-36V | NPN | NO 常开 | FJ2-M10NA | FJ2-15NA |
| NC 常闭 | FJ2-M10NB | FJ2-15NB | ||
| NO+NC 常开常闭 | FJ2-M10NC | FJ2-15NC | ||
| PNP | NO 常开 | FJ2-M10PA | FJ2-15PA | |
| NC 常闭 | FJ2-M10PB | FJ2-15PB | ||
| NO+NC 常开常闭 | FJ2-M10PC | FJ2-15PC | ||
| 二线制 | NO 常开 | FJ2-M10LA | FJ2-15LA | |
| NC 常闭 | FJ2-M10LB | FJ2-15LB | ||
| 输出电压降DC/AC | AC<8V ,DC三线<1.5V ,DC二线<4V | |||
| 输出电流 | 可控硅SCR 300mA 继电器1A、2A DC三线200mA DC二线 50mA | |||
| 重复精度 | ≤10% | |||
| 消耗电流 | <10mA | |||
| 响应频率 | DC 200Hz,AC 25Hz | DC 100Hz,AC 25Hz | ||
| 外壳体材料 | 塑料ABS | |||
| 设定距离 | 0-8mm | 0-12mm | ||
| 标准检测物体 | 50×50×1 | |||
| 工作环境温度 | -20℃~+55℃ | |||
| 连接方式 | 1.5m PVC电缆 | |||
| 防护等级 | IP67 | |||
